Specifications
MACHINE CONFIGURATION
(Options and accessories included with this machine)
- Motor start/stop pushbuttons
- "Quick Lock" squaring fence
- Fence for angular cutting on sliding carriage
- Expandable scoring blade
- Saw blade 350 mm
TECHNICAL FEATURES | ||
Blades tilting | 90° ÷ 45° | |
Max. saw blade diam. with scoring blade installed | mm (in) | 350 (13.75”) |
Max. saw blade projection from table at 90°/45° | mm (in) | 118/81 (4.62 / 3.19”) |
Scoring blade diameter | mm (in) | 120 (4.75”) |
Squaring stroke | mm (in) | 3200 (10.5’) |
Cutting width on parallel fence | mm (in) | 1270 (49.94”) |
Other technical features: | ||
Three-phase motor | 8kW (11hp) 60Hz | |
Exhaust outlets diameter | 120 (4.75”) | |
MINIMUM INSTALLATION REQUIREMENTS | ||
Power absorption | A | 30 |
Voltage frequency | 230V 60Hz |
Design features
Optimal support also to larger pieces, with
the sliding table 400 mm wide. The slideways, with special arch-ground steel profile (SCM solution), are secured with a procedure of aluminum riveting so that to ensure an exceptional precision and smoothness.
The saw blade lifting of the saw unit is carried out by a sturdy cast-iron structure with sliding on ground round slideways which guarantee the best accuracy. The unit tilting is carried out on cast-iron rotation sectors in a crescent shape to ensure reliability over time.
Panel loading is easy on the large and sturdy squaring frame with an extending roller at the end. The "Quick Lock" squaring fence with rapid release SCM system minimizes set-up times granting an extremely fast fence positioning.
SCM Thundercut App for mobile devices: optimizer/sequencer even for not skilled workers.
All the handwheels are on the machine front: always user friendly and precise. The dedicated gears box (SCM solution), fully protected from dust, provides a smooth and direct transmission so that every minimum handwheel movement corresponds to a precise blade adjustment.
