Specifications
MACHINE CONFIGURATION
(Options and accessories included with this machine)
- Ripping capacity on parallel fence 1270 mm
- Expandable scoring blade
- Eccentric clamp
- Saw blade 315 mm
- Overhead saw guard with incorporated dust extraction
TECHNICAL FEATURES
blades tilting |
| 90° ÷ 45° |
max. saw blade diam. with scoring blade installed | [mm] | 315 (15.37”) |
max. saw blade projection from table at 90°/45° | [mm] | 100/70 (3.87”/2.75”) |
scoring blade diameter | [mm] | 120 (4.75”) |
squaring stroke | [mm] | 1600 (62.94”) |
cutting width on parallel fence | [mm] | 1270 (49.94”) |
Other technical features: |
|
|
three-phase motor |
| 6kW (8hp) 60Hz |
exhaust outlets diameter | [mm] | 120 (4.75”) |
USA version Voltage-Frequency 220V-60Hz
Design features
The saw blade lifting of the saw unit is carried out by a sturdy cast-iron structure with sliding on ground round slideways which guarantee the best accuracy. The unit tilting is carried out on cast-iron rotation sectors in a crescent shape to ensure reliability over time
Optimal support also to larger pieces, with the sliding table 360 mm (14.19”) wide. The carriage sliding system is guaranteed for 10 years: a proof of reliability and technology without comparisons
Vertical and horizontal adjustments of the scoring unit are carried out by user-friendly mechanical levers that operate directly making precise and smooth movements. The useful mechanical stops allows immediately finding of the set position
All the handwheels are on the machine front: always user friendly and precise. The dedicated gears box (SCM solution), fully protected from dust, provides a smooth and direct transmission so that every minimum handwheel movement corresponds to a precise blade adjustment
SCM Thundercut App for mobile devices: optimizer/sequencer even for not skilled workers
