Specifications
MACHINE CONFIGURATION
(Options and accessories included with this machine)
- Belt driven scoring unit complete with blade
- Cutting width with parallel fence 1270 mm
- 2 squaring flip-over stops
- Single-phase motor 3kW (4hp) 60Hz
TECHNICAL FEATURES |
| |
Cast iron worktable dimensions | mm (in) | 1020 x 325 (40.12 x 12.81”) |
Blade tilting | mm | 90° ÷ 45° |
Max. blade diameter with scoring blade installed | mm (in) | 315 (12.37”) |
Max. saw blade projection from table at 90°/45° | mm (in) | 100/78 (3.87 / 3”) |
Max. squaring stroke | mm (in) | 1600 (62.94”) |
Cutting width on parallel fence | mm (in) | 1270 (49.94”) |
Other technical features: |
| |
Single-phase motor | 3kW (4hp) 60Hz | |
Exhaust outlets diameter | mm (in) | 120 (4.75”) |
USA version Voltage-Frequency | 230V-60Hz |
Design features
The scoring unit adjustment complete with blade is carried out from outside the machine by means of with special knobs and without the necessity of keys
An incredible cutting with the saw unit with 315mm maximum blade diameter with the scoring blade installed
